Scanner Configuration - Datalogic Scanners

The DataLogic scanners can be configured using the Settings app (cog icon) and selecting System -> Scanner settings.

The settings are detailed in this video, go back into the StoreFeeder WMS app once set and perform a barcode scan.

From the device main screen open Settings -> System -> Scanner settings -> Wedge

Enable keyboard wedge should be off
Enable intent wedge should be on
Intent output must be enabled
Intent delivery should be broadcast intent
Intent action should be "com.sf.barcode.action"
Intent category should be "com.sf.barcode.category"

Some devices also have Intent extra barcode string. Set this to "barcode"

IMPORTANT* - Click commit to save the changes. This is on the Scanner settings page where the Wedge option resides.

Go back into the StoreFeeder WMS app.

From the slide in menu select Settings -> On Device Scanner Configuration -> I have updated the settings.

Click "I'm ready to scan" and scan barcode 12345678. If successful a message will appear at the bottom of the screen "Scanner configured successfully".

An ideal test is to go to Products from the slide in main menu and scan a barcode. You should not have to touch the screen or click Search. The barcode scan will populate the search field and perform the search.

This video is for a DataLogic Memor 1 but may be applicable to other DataLogic scanners. It has been tested on a Memor 10.
